HT 530-A Universal Kit
HT 530-A Universal kit - 230 V / 2300 W / EU-plug
- Configurable, multifunctional button (Miracle Key)
- Sensor-controlled Eco mode saves energy
- Quick temperature selection via multifunction knob
- Adjustable temperature limiter
- Five accessories included in the set
The HT 530-A universal kit from Weldy includes a powerful and handy Weldy HT 530 heat gun, among other accessories. This has a separate cooling stage and five blower settings, with adjustable temperature settings between 80 °C to 650 °C. In addition, the Weldy HT 530-A heat gun is equipped with a configurable pull key (Miracle Key). This button can be used to select Eco mode, as well as fixed temperatures.
The HT 530-A universal kit designed for beginners with a good price-performance ratio is suitable for versatile, indoor plastic welding work like activating adhesives, removing paint and varnish, shaping plastic profiles, shrinking protective tubing, processing leather, artificial leather and technical textiles, etc. For optimal, ergonomic and safe working, the spring balancer (article no. 154.089) and the burn protection (article no. 165.036) are recommended as optional accessories.
Scope of delivery
- HT 530-A
- Wide slot nozzle (article no. 119.346
- tube nozzle (article no. 119.345)
- spoon reflector (article no. 119.344)
- solder reflector (article no. 119.347)
- pressure roller (article no. 119.348)
Accessories

Spring balancer (fuego HG1600)
Order number: 154.089
Price: CHF 12.20

Vinyl trimmer guide
Order number: 132.050
Price: CHF 5.00

Prof. quartermoon knife
Order number: 153.894
Price: CHF 19.10

Silicone pressure roller 40 mm
Order number: 130.611
Price: CHF 32.90

Silicon Pressure roller 30 mm
Order number: 130.146
Price: CHF 32.90

Scraper with wooden handle
Order number: 119.177
Price: CHF 7.40

Protective tube
Order number: 165.036
Price: CHF 34.30
Nozzles

Speed welding nozzle 5 mm
Order number: 125.315
Price: CHF 13.60

Speed welding nozzle 7 mm triangle (energy HT1600)
Order number: 127.833
Price: CHF 13.60

Tacking nozzle (energy HT1600)
Order number: 147.248
Price: CHF 13.60

Speed welding nozzle 4 mm (energy HT1600)
Order number: 146.740
Price: CHF 13.60

welding nozzle (PLUS S)
Order number: 119.345
Price: CHF 7.80

solder sleeve reflector nozzle (PLUS S)
Order number: 119.347
Price: CHF 12.80

reflector nozzle (energy HT1600 & PIC / PRO / PLUS S)
Order number: 119.344
Price: CHF 7.80

overlap welding nozzle (PLUS S)
Order number: 119.346
Price: CHF 7.80
Specifications
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 230 |
| Power | W | 2300 |
| Temperature | °C | 80 - 650 |
| Air volume (20 °C) | l/min | 200 - 550 |
| Weight | kg | 0.7 |
| Frequency | Hz | 50/60 |
| Conformity mark (CE) | ![]() | |
| Protection class II | ![]() |
Downloads
Generel Catalog
Flyers
Manuals
Order number: 129.552
Lieferfrist: 5 - 7 days
Warranty: 1 year bring in
Price: CHF 167.40
excl. VAT
